Executive 308/308L-Data Sheet
Download
Executive 308/308L-Safety Data Sheet
Download
Executive 308/308L-Line Sheet
Download
Executive 308/308L provides superior weldability, low spatter and smooth beads with easy slag removal. Austenitic stainless steel flux cored wire. Due to the lower carbon content in the weld deposit, it is possible to obtain resistance to inter granular corrosion even though used in as-weld condition. This wire is designed to be used in the flat/horizontal position. Low carbon in this filler metal reduces the possibility of intergranular carbide precipitation. This increases the resistance to intergranular corrosion without the use of stabilizers such as niobium or titanium. Strength of this low-carbon alloy, however, is less than that of the niobium-stabilized alloys or Type 308H at elevated temperatures.
Application and Features
Generally used with 100% CO2 shielding gas or mixtures of Ar+20~25% CO2. Used to join 301, 302, and 304 stainless steel. This alloy may also be used for welding types 321 and 347 if the service conditions do not exceed 750F (399C). This is also available in a thin gauge (TG) Executive 308/308LTG in .045" diameter for thin plate welding. It offers wider current ranges (as low as 85 Amps) typically only achieved with costly .035" wire, thus offering a substantial savings.
Typical Wire Chemistry and Mechanicals
C | Cr | Ni | Mo | Mn | Si | P | S | Cu |
---|---|---|---|---|---|---|---|---|
0.02 | 18.88 | 9.03 | 0.08 | 1.47 | 0.97 | 0.02 | 0.01 | 0.10 |
Tensile Strength: | 78,900 PSI min | Elongation: | 42% |
Yield Strength: | 61,100 PSI min |
Typical Welding Parameters
Diameter | Voltage | Amperage | WFS (in/min) | Shielding Gas* |
---|---|---|---|---|
.045 TG | 18-21 | 85 | 140 | 100% C02 or Ar + 20-25% C02 |
.045 TG | 26-29 | 165 | 300 | |
.045 TG | 28-34 | 215 | 500 | |
.045" | 24 | 130 | 225 | 100% C02 or Ar + 20-25% C02 |
.045" | 27 | 175 | 320 | |
.045" | 30 | 240 | 530 | |
.062" | 27 | 195 | 152 | 100% C02 or Ar + 20-25% C02 |
.062" | 31 | 260 | 260 | |
.062" | 34 | 320 | 360 |
*Shielding gas flow rate 35 to 50 CFH. For 100% CO2 use two volts higher than shown
Standard Packaging
FCAW | 33-lb plastic spools | 1,980-lb pallet |
Classification
AWS/SFA 5.22, Class E308/308LT0-1/4
