Executive C-276 is a nickel-chromium-molybdenum alloy designed for welding alloy C-276 and other similar alloys using MIG, TIG and SAW welding processes. The weld metal has excellent corrosion resistance in many aggressive media and is especially resistant to pitting and crevice corrosion. Executive C-276 filler metal is produced using high quality raw materials and tightly controlled chemistry to provide top quality, exceptionally clean wires that deliver the results fabricators demand. Use Executive C-276 FC where flux cored wire is suited to the application.
Application and Features
Executive C-276 is a versatile filler metal that is used for surfacing steel as well as joining C-276 material to itself and to other molybdenum bearing nickel alloys, stainless steels and low alloys steels. Executive C-276 can also be used to weld ASTM B574, B575, B19, B622, and B628 materials.
This wire is also suitable for laser welding and WAAM applications (Wire Arc Additive Manufacturing, aka Metal 3D printing).
Typical Wire Chemistry and Mechanicals
C | Mn | Fe | P | S | Si | Cu | Ni | W | Co | Cr | V | Mo |
---|---|---|---|---|---|---|---|---|---|---|---|---|
0.01 | 0.50 | 5.7 | 0.004 | 0.001 | 0.05 | 0.02 | 58.1 | 3.7 | <0.01 | 15.7 | <0.01 | 15.9 |
Tensile Strength: | 100,000 PSI min | Elongation: | 30% |
Typical Welding Parameters
Process | Diameter | Voltage | Amperage | Gas Flow | Shielding Gas / Flux |
---|---|---|---|---|---|
GMAW -Short | .035" | 17-20 | 70-90 | 30 to 50 CFH | 90% Ar 75% Ar / 25% He 90% He / 7.5% Ar / 2.5% C02 |
.045" | 19-22 | 75-160 | |||
-Spray | .045" | 30-32 | 190-250 | ||
-Pulse | .045" | 18-20 | 120-150 | ||
GTAW | .062" - .125" | Direct Current; Electrode- | 30 to 40 CFH | 100% Ar | |
SAW | .062" | 28-32 | 250-280 | NiCr-W Flux | |
.093" | 28-32 | 275-350 | |||
.125" | 29-34 | 350-450 |
Standard Packaging
GMAW (MIG) | 33-lb wire baskets | 500-lb Drum |
GTAW (TIG) | 10-lb plastic tubes | 40-lb box |
SAW (SUBARC) | 60-lb wire coil | |
60-lb Arco Pak |
Classification
AWS/SFA 5.14, Class ERNiCrMo-4
